product overview
Lithium calcium complex grease is a kind of semi-fluid grease with excellent properties, which is madeby thickening refined mineral oil with hydroxy-fatty acid lithium soap and adding extreme pressureanti-wear additives.
performance characteristic
Excellent extreme pressure, anti-wear performance, effectively prevent tooth surface spallingpitting, prolong the service life of the reducer.
Excellent oxidation resistance and mechanical stability.
Excellent rust and corrosion prevention.
Recommended application
Suitable for non-cyclic lubrication reducer gear lubrication.
No. 00 is suitable for gear center distance less than 400mm reducer
No. 0 is suitable for gear center distance more than 400mm reducer
Operating temperature: -20°C ~120C
Typical data
|
Item |
Typical data |
Test method | |
|
NLGI 2 |
NLGI 3 |
||
|
Worked cone penetration，0.1mm |
417 | 368 | GB/T 269 |
|
dropping point，℃ |
175 | 176 | GB/T 4929 |
|
corrosion(T2 copper，100°C,24h) |
Up to standard | GB/T 7326(B) | |
|
Penetration change after 100000 strokes 0.1mm |
412 | 378 | GB/T 269 |
|
Anti-corrosion property(52℃,48h) |
Up to standard | GB/T 5018 | |
|
carrying capacity (four ball method) PB value,N |
> 588 | >156 | GB/T 3142 |
|
carrying capacity (Timken method) OK value,N |
>133 | >133 | SH/T 0203 |
